Littelfuse 0451020.MRL 20A 65V Very Fast-Acting NANO² SMD Fuse

Name: Littelfuse 0451020.MRL 20A 65V Very Fast-Acting NANO² SMD Fuse
Brand: Littelfuse
SKU: 0451020.MRL

Part Number: 0451020.MRL

● Contact for Availability

Littelfuse 0451020.MRL provides 20A/65V AC/DC protection with very fast-acting characteristics and 100A @65VAC interrupting capacity.

Rated Current20A

Rated Voltage65V AC/DC

Breaking Capacity100A @65VAC

PackageSMD 2410

Tags

0451020.MRL 20A 451 Series 65V Littelfuse SMD 2410 Very Fast Acting

The 0451020.MRL from Littelfuse’s 451 Series provides very fast-acting protection at 20A and 65V AC/DC. With 6.10 × 2.69 × 2.69mm dimensions and a 100A @65VAC interrupting rating, the fuse suits the listed smd mounting style. This part is cataloged for power electronics, telecom dc and battery charging and carries CE, UKCA, RoHS and Halogen Free; UL/CSA/PSE approvals vary by ampere rating approvals under UL 248-14|IEC 60127-7. Listed I²t: Nominal melting: 154 A²s.

Technical Specifications

Part Number: 0451020.MRL
Manufacturer Part Number: 0451020.MRL
Series: 451 Series
Fuse Type: NANO² Very Fast-Acting SMD Fuse
Current Rating: 20A
Voltage Rating: 65V AC/DC
AC / DC: AC/DC
Breaking Capacity: 100A @65VAC
I²t: Nominal melting: 154 A²s
Pre-arcing I²t: 154
Operating Temperature: -55°C to +125°C
Package / Dimensions: SMD 2410
Mounting: SMD
Application: Battery chargers · Power Electronics · Telecom DC distribution
Standard: IEC 60127-7 · UL 248-14
Terminal Type: End Cap
Fuse Speed: Very Fast Acting
Utilization Class: Supplemental
Approvals: CE · RoHS
Certifications: CE · UKCA · RoHS · Halogen Free; UL/CSA/PSE approvals vary by ampere rating
Body: Ceramic
Packaging: 1000 pcs Tape & Reel
Moisture Sensitivity Level: 1
Nominal melting I²t: 154 A²s
