Littelfuse 0326.100MXDP pairs a 0.1A current rating with 250V AC operation in the 326 Series. Its protection profile centers on 3AB Slo-Blo ceramic fuse operation plus 100A @ 250VAC fault interruption. Order-code suffix MXDP identifies this packaging/configuration. Final selection should follow the published Littelfuse specifications.
Submit directly from this product page. We will reply with availability, lead time and pricing.
Part 0326.100MXDP from the Littelfuse 326 Series is specified at 0.1A and 250V AC. A 6.3×32mm body supports cartridge / clip installation, and the manufacturer lists 100A @ 250VAC as the principal interrupting capability. Published dimensions for this rating/configuration are 32.72 × 6.985mm body. The MXDP suffix denotes bulk pack code mxdp (1000 pcs; higher-i²t d variant). Because this is the higher-I²t D variant, the standard-series I²t value is intentionally not reused. It is intended for Appliances, Utilization Equipment, Internal Circuit Protection. Validate the final circuit against UL 248-14, approvals and the official technical data.
