Littelfuse

Littelfuse 032502.5VXP 2.5A 250V 3AB Slo-Blo Axial Fuse

Name: Littelfuse 032502.5VXP 2.5A 250V 3AB Slo-Blo Axial Fuse
Brand: Littelfuse
SKU: 032502.5VXP

Part Number: 032502.5VXP

● Contact for Availability

A 2.5A 3AB Slo-Blo axial fuse, 032502.5VXP is supplied in a 5-piece bulk configuration for supplementary equipment protection.

Rated Current2.5A

Rated Voltage250V AC

Breaking Capacity100A @ 250VAC

Package6.3×32mm

Tags

032502.5VXP 2.5A 250V 325 Series 3AB Slo-Blo Axial Fuse Littelfuse

For appliance and internal-circuit protection, 032502.5VXP combines a 2.5A rating with a 6.3×32mm ceramic axial-lead format. The datasheet lists nominal melting I²t of 185 A²s for this ampere code. This SKU uses the 5-piece bulk configuration; Confirm system-level suitability against the manufacturer technical data. For cross-reference work, compare its application category before the series designation, and verify the terminal style against the Littelfuse technical sheet.

Technical Specifications

Part Number: 032502.5VXP
Manufacturer Part Number: 032502.5VXP
Series: 325 Series
Fuse Type: 3AB Slo-Blo Ceramic Axial Lead Fuse
Current Rating: 2.5A
Voltage Rating: 250V AC
AC / DC: AC
Breaking Capacity: 100A @ 250VAC
I²t: 185 A²s
Operating Temperature: -55°C to +125°C
Package / Dimensions: 6.3×32mm
Mounting: PCB Through-Hole
Application: Appliances · Internal Circuit Protection · PCB protection · Utilization Equipment
Standard: UL 248-14
Terminal Type: Axial Leads
Fuse Speed: Time Delay
Utilization Class: Supplemental
Approvals: RoHS
Certifications: RoHS · Lead-Free; agency approvals vary by ampere rating/configuration
Body: Ceramic
Caps: Nickel-plated brass
Leads: Tin-plated copper
Packaging/configuration: Bulk pack code VX (5 pcs)
Nominal melting I²t: 185 A²s
