Littelfuse 0324040MX52LP 40A 250V Fast-Acting 3AB Axial Lead Fuse

Littelfuse

Littelfuse 0324040MX52LP 40A 250V Fast-Acting 3AB Axial Lead Fuse

Part Number: 0324040MX52LP

● Contact for Availability

The 324 Series 0324040MX52LP is a Littelfuse 3AB fast-acting axial lead fuse rated 40A at 250V AC, suited to appliances and power electronics.

Rated Current40A

Rated Voltage250V AC

Breaking Capacity1000A @250VAC

Package6.3×32mm

Tags

0324040MX52LP 250V 324 Series 40A 6.3×32mm fast acting (f)Littelfuse

Within the 324 Series, Littelfuse 0324040MX52LP is specified for 40A service at 250V AC. The device uses axial lead terminals in a 6.3×32mm body and carries a 1000A @250VAC interrupting rating. The listed application set covers appliances and power electronics. Standards and approvals include UL 248-14 and CE and RoHS; UL/CSA/PSE approvals vary by ampere rating. Listed I²t: Nominal melting: 22925 A²s.

Technical Specifications

Part Number: 0324040MX52LP
Manufacturer Part Number: 0324040MX52LP
Series: 324 Series
Fuse Type: 3AB Fast-Acting Axial Lead Fuse
Current Rating: 40A
Voltage Rating: 250V AC
AC / DC: AC
Breaking Capacity: 1000A @250VAC
I²t: Nominal melting: 22925 A²s
Pre-arcing I²t: 22925
Operating Temperature: -55°C to +125°C
Package / Dimensions: 6.3×32mm
Mounting: PCB Through-Hole
Application: Appliances · Power Electronics
Standard: UL 248-14
Terminal Type: Axial Lead
Fuse Speed: Fast Acting (F)
Utilization Class: Supplemental
Approvals: CE · RoHS
Certifications: CE · RoHS; UL/CSA/PSE approvals vary by ampere rating
Body: Ceramic
Cap: Nickel-plated brass
Leads: Tin-plated copper
Nominal melting I²t: 22925 A²s

Downloads

DatasheetOpen / download →
