Littelfuse

Littelfuse 0324030HXP 30A 250V Fast-Acting 3AB Axial Lead Fuse

Name: Littelfuse 0324030HXP 30A 250V Fast-Acting 3AB Axial Lead Fuse
Brand: Littelfuse
SKU: 0324030HXP

Part Number: 0324030HXP

● Contact for Availability

Littelfuse 0324030HXP offers fast-acting protection at 30A and 250V AC, with CE and RoHS; UL/CSA/PSE approvals vary by ampere rating approvals.

Rated Current30A

Rated Voltage250V AC

Breaking Capacity100A @250VAC

Package6.3×32mm

Tags

0324030HXP 250V 30A 324 Series 6.3×32mm fast acting (f)Littelfuse

0324030HXP is the 30A version of Littelfuse’s 324 Series, using fast-acting characteristics at 250V AC. With 32.72 × 6.985mm body; 38.1mm typical axial leads dimensions and a 100A @250VAC interrupting rating, the fuse suits the listed pcb through-hole mounting style. The listed application set covers appliances and power electronics. Standards and approvals include UL 248-14 and CE and RoHS; UL/CSA/PSE approvals vary by ampere rating. Listed I²t: Nominal melting: 2490 A²s.
