Littelfuse

Littelfuse 0324010MXP 10A 250V Fast-Acting 3AB Axial Lead Fuse

Name: Littelfuse 0324010MXP 10A 250V Fast-Acting 3AB Axial Lead Fuse
Brand: Littelfuse
SKU: 0324010MXP

Part Number: 0324010MXP

● Contact for Availability

Littelfuse 0324010MXP provides 10A/250V AC protection with fast-acting characteristics and 750A @250VAC interrupting capacity.

Rated Current10A

Rated Voltage250V AC

Breaking Capacity750A @250VAC

Package6.3×32mm

Tags

0324010MXP 10A 250V 324 Series 6.3×32mm fast acting (f)Littelfuse

The 324 Series 0324010MXP is a Littelfuse 3AB fast-acting axial lead fuse for 10A, 250V AC protection. Key construction details include 6.3×32mm, 32.72 × 6.985mm body; 38.1mm typical axial leads and axial lead terminals, plus a 750A @250VAC interrupting rating. The listed application set covers appliances and power electronics. Standards and approvals include UL 248-14 and CE and RoHS; UL/CSA/PSE approvals vary by ampere rating. Listed I²t: Nominal melting: 206 A²s.
