Littelfuse 0324005MX52LP 5A 250V Fast-Acting 3AB Axial Lead Fuse

Name: Littelfuse 0324005MX52LP 5A 250V Fast-Acting 3AB Axial Lead Fuse
Brand: Littelfuse
SKU: 0324005MX52LP

Part Number: 0324005MX52LP

● Contact for Availability

Littelfuse 0324005MX52LP offers fast-acting protection at 5A and 250V AC, with CE and RoHS; UL/CSA/PSE approvals vary by ampere rating approvals.

Rated Current5A

Rated Voltage250V AC

Breaking Capacity750A @250VAC

Package6.3×32mm

Tags

0324005MX52LP 250V 324 Series 5A 6.3×32mm fast acting (f)Littelfuse

Within the 324 Series, Littelfuse 0324005MX52LP is specified for 5A service at 250V AC. The 6.3×32mm format measures 32.72 × 6.985mm body; 52mm long axial leads and uses axial lead terminations; interrupting capacity is 750A @250VAC. The listed application set covers appliances and power electronics. Standards and approvals include UL 248-14 and CE and RoHS; UL/CSA/PSE approvals vary by ampere rating. Listed I²t: Nominal melting: 26 A²s.
