Littelfuse 0324003MXF24P 3A 250V Fast-Acting 3AB Axial Lead Fuse
● Contact for AvailabilityChoose Littelfuse 0324003MXF24P for 3A, 250V AC fast-acting circuit protection with a 100A @250VAC interrupting rating.
Rated Current3A
Rated Voltage250V AC
Breaking Capacity100A @250VAC
Package6.3×32mm
QUICK RFQ
Request a quote for 0324003MXF24P
Submit directly from this product page. We will reply with availability, lead time and pricing.
Part Number0324003MXF24PBrandLittelfuseRequested Qty100
Littelfuse 0324003MXF24P combines a 3A rating and 250V AC capability with fast-acting fuse behavior. Its 100A @250VAC interrupting rating and 6.3×32mm package support pcb through-hole installations. The listed application set covers appliances and power electronics. Standards and approvals include UL 248-14 and CE and RoHS; UL/CSA/PSE approvals vary by ampere rating. Listed I²t: Nominal melting: 14.6 A²s.
Technical Specifications
- Part Number
- 0324003MXF24P
- Manufacturer Part Number
- 0324003MXF24P
- Series
- 324 Series
- Fuse Type
- 3AB Fast-Acting Axial Lead Fuse
- Current Rating
- 3A
- Voltage Rating
- 250V AC
- AC / DC
- AC
- Breaking Capacity
- 100A @250VAC
- I²t
- Nominal melting: 14.6 A²s
- Pre-arcing I²t
- 14.6
- Operating Temperature
- -55°C to +125°C
- Package / Dimensions
- 6.3×32mm
- Mounting
- PCB Through-Hole
- Application
- Appliances · Power Electronics
- Standard
- UL 248-14
- Terminal Type
- Axial Lead
- Fuse Speed
- Fast Acting (F)
- Utilization Class
- Supplemental
- Approvals
- CE · RoHS
- Certifications
- CE · RoHS; UL/CSA/PSE approvals vary by ampere rating
- Body
- Ceramic
- Cap
- Nickel-plated brass
- Leads
- Tin-plated copper
- Nominal melting I²t
- 14.6 A²s
