Littelfuse 0324002MXF24P 2A 250V Fast-Acting 3AB Axial Lead Fuse
● Contact for AvailabilityLittelfuse 0324002MXF24P offers fast-acting protection at 2A and 250V AC, with CE and RoHS; UL/CSA/PSE approvals vary by ampere rating approvals.
Rated Current2A
Rated Voltage250V AC
Breaking Capacity100A @250VAC
Package6.3×32mm
QUICK RFQ
Request a quote for 0324002MXF24P
Submit directly from this product page. We will reply with availability, lead time and pricing.
Part Number0324002MXF24PBrandLittelfuseRequested Qty100
Rated 2A at 250V AC, Littelfuse 0324002MXF24P is a 3AB fast-acting axial lead fuse in the 324 Series. Its 100A @250VAC interrupting rating and 6.3×32mm package support pcb through-hole installations. The listed application set covers appliances and power electronics. Standards and approvals include UL 248-14 and CE and RoHS; UL/CSA/PSE approvals vary by ampere rating. Listed I²t: Nominal melting: 5.7 A²s.
Technical Specifications
- Part Number
- 0324002MXF24P
- Manufacturer Part Number
- 0324002MXF24P
- Series
- 324 Series
- Fuse Type
- 3AB Fast-Acting Axial Lead Fuse
- Current Rating
- 2A
- Voltage Rating
- 250V AC
- AC / DC
- AC
- Breaking Capacity
- 100A @250VAC
- I²t
- Nominal melting: 5.7 A²s
- Pre-arcing I²t
- 5.7
- Operating Temperature
- -55°C to +125°C
- Package / Dimensions
- 6.3×32mm
- Mounting
- PCB Through-Hole
- Application
- Appliances · Power Electronics
- Standard
- UL 248-14
- Terminal Type
- Axial Lead
- Fuse Speed
- Fast Acting (F)
- Utilization Class
- Supplemental
- Approvals
- CE · RoHS
- Certifications
- CE · RoHS; UL/CSA/PSE approvals vary by ampere rating
- Body
- Ceramic
- Cap
- Nickel-plated brass
- Leads
- Tin-plated copper
- Nominal melting I²t
- 5.7 A²s
