Littelfuse

Littelfuse 0324001 1A 250V Fast-Acting 3AB Axial Lead Fuse

Name: Littelfuse 0324001 1A 250V Fast-Acting 3AB Axial Lead Fuse
Brand: Littelfuse
SKU: 0324001

Part Number: 0324001

● Contact for Availability

Littelfuse 0324001 is rated 1A at 250V AC and provides fast-acting protection in a 6.3×32mm format for appliances and power electronics.

Rated Current1A

Rated Voltage250V AC

Breaking Capacity100A @250VAC

Package6.3×32mm

Tags

0324001 1A 250V 324 Series 6.3×32mm fast acting (f)Littelfuse

Littelfuse 0324001 combines a 1A rating and 250V AC capability with fast-acting fuse behavior. Physical configuration is 6.3×32mm (32.72 × 6.985mm body; 38.1mm typical axial leads), with axial lead terminals and 100A @250VAC interrupting capability. For appliances and power electronics, confirm final circuit suitability using the datasheet, UL 248-14 and applicable CE and RoHS; UL/CSA/PSE approvals vary by ampere rating marks. Listed I²t: Nominal melting: 0.69 A²s.
