Littelfuse 0315002HXP 2A Slo-Blo 3AG Axial Lead Fuse
Littelfuse

Littelfuse 0315002HXP 2A Slo-Blo 3AG Axial Lead Fuse

Part Number: 0315002HXP

● Contact for Availability

0315002HXP is a 2A 3AG slo-blo axial lead fuse from Littelfuse, rated 250V AC for appliances and power electronics.

Rated Current2A
Rated Voltage250V AC
Breaking Capacity100A
Package6.3×32mm
Tags
Share

Rated 2A at 250V AC, Littelfuse 0315002HXP is a 3AG slo-blo axial lead fuse in the 315 Series. Electrical protection is backed by a 100A breaking capacity, with pcb through-hole mounting in the 6.3×32mm format. It is positioned for appliances and power electronics, with UL 248-14 as the listed product standard and CE and RoHS; UL/CSA/PSE approvals vary by ampere rating certifications.

Technical Specifications

Part Number
0315002HXP
Manufacturer Part Number
0315002HXP
Series
315 Series
Fuse Type
3AG Slo-Blo Axial Lead Fuse
Current Rating
2A
Voltage Rating
250V AC
AC / DC
AC
Breaking Capacity
100A
Operating Temperature
-60°C to +125°C
Package / Dimensions
6.3×32mm
Mounting
PCB Through-Hole
Application
Appliances · Power Electronics
Standard
UL 248-14
Terminal Type
Axial Lead
Fuse Speed
Time Delay
Utilization Class
Supplemental
Approvals
CE · RoHS
Certifications
CE · RoHS; UL/CSA/PSE approvals vary by ampere rating
Body
Glass

Downloads

DatasheetOpen / download →
