Littelfuse 0315.040MXP 0.04A Slo-Blo 3AG Axial Lead Fuse

Name: Littelfuse 0315.040MXP 0.04A Slo-Blo 3AG Axial Lead Fuse
Brand: Littelfuse
SKU: 0315.040MXP

Part Number: 0315.040MXP

● Contact for Availability

Built for appliances and power electronics, Littelfuse 0315.040MXP combines 0.04A protection, 250V AC capability and a 6.3×32mm form factor.

Rated Current0.04A

Rated Voltage250V AC

Breaking Capacity35A

Package6.3×32mm

Tags

0.04A 0315.040MXP 250V 315 Series 6.3×32mm Littelfuse time-delay

Littelfuse’s 0315.040MXP is a 0.04A 3AG slo-blo axial lead fuse rated for 250V AC operation. Its pcb through-hole form factor, 6.3×32mm size and 35A rating define the core installation limits. Use cases in the catalog include appliances and power electronics. Compliance references include UL 248-14 and CE and RoHS; UL/CSA/PSE approvals vary by ampere rating.
