Littelfuse 02321.25MXEP 1.25A 5×20mm Medium-Acting Glass Fuse

Name: Littelfuse 02321.25MXEP 1.25A 5×20mm Medium-Acting Glass Fuse
Brand: Littelfuse
SKU: 02321.25MXEP

Part Number: 02321.25MXEP

● Contact for Availability

02321.25MXEP is a 1.25A Littelfuse 232 Series device; axial lead, bulk, with published series ratings and ordering-specific configuration.

Rated Current1.25A

Rated Voltage250 V AC

Breaking Capacity10 kA @ 125 VAC; 35 A @ 250 VAC

Package5×20mm

Tags

02321.25MXEP 1.25A 232 Series 5×20mm Glass Fuse Axial lead, bulk Littelfuse

Littelfuse identifies 02321.25MXEP as a 1.25A member of the 232 Series, intended for medium-acting 5×20mm glass fuse applications. The selected part uses axial lead, bulk. The full ordering code specifies axial lead, bulk, so package and lead details should be matched exactly. It is rated 250 V AC and the datasheet lists 10 kA @ 125 VAC; 35 A @ 250 VAC interrupting capability. Nominal melting I²t is 4.11 A²s. Verify ambient derating, coordination and the exact manufacturer ordering code against the current Littelfuse datasheet before design-in.

Technical Specifications

Part Number: 02321.25MXEP
Manufacturer Part Number: 02321.25MXEP
Series: 232 Series
Fuse Type: 5×20mm Glass Fuse
Current Rating: 1.25A
Voltage Rating: 250 V AC
AC / DC: AC
Breaking Capacity: 10 kA @ 125 VAC; 35 A @ 250 VAC
I²t: 4.11 A²s nominal melting I²t
Pre-arcing I²t: 4.11
Operating Temperature: -60°C to +125°C
Package / Dimensions: 5×20mm
Mounting: PCB Axial Lead · PCB Through-Hole
Application: Supplementary protection for appliances, utilization equipment, components and internal circuits
Standard: DENAN Appendix 3
Terminal Type: Tin-plated copper axial leads
Fuse Speed: Medium Acting
Approvals: CE · RoHS
Certifications: PSE; KC; CE; RoHS
Package/configuration: Axial lead, bulk. Glass body; tin-plated copper leads. Nominal melting I²t: 4.11 A²s. Series operating temperature: -60°C to +125°C.
