Littelfuse 023003.5DRT3P 3.5A 2AG Tape/Reel Time-Delay Fuse
● Contact for AvailabilityA 3.5 A axial-leaded 2AG time-delay fuse from Littelfuse 230 Series, 023003.5DRT3P is identified by its reel and tape DRT3 configuration order configuration.
Rated Current3.5 A
Rated Voltage250 V AC / 125 V DC
Breaking Capacity100 A @ 250 VAC; 10 kA @ 125 VAC/VDC
Package2AG (4.5×15mm)
QUICK RFQ
Request a quote for 023003.5DRT3P
Submit directly from this product page. We will reply with availability, lead time and pricing.
Part Number023003.5DRT3PBrandLittelfuseRequested Qty100
Part 023003.5DRT3P is the 3.5 A axial-leaded member of Littelfuse’s 230 Series Slo-Blo family. For coordination work, the manufacturer lists 110 A²s nominal melting I²t and 100 A @ 250 VAC; 10 kA @ 125 VAC/VDC. This variant is supplied under a code representing reel-and-tape packaging, 1,500 pieces, T3=73 mm; verify the required packaging before production release.
Technical Specifications
- Part Number
- 023003.5DRT3P
- Manufacturer Part Number
- 023003.5DRT3P
- Series
- 230 Series
- Fuse Type
- 2AG Glass Axial Lead Fuse
- Current Rating
- 3.5 A
- Voltage Rating
- 250 V AC / 125 V DC
- AC / DC
- AC/DC
- Breaking Capacity
- 100 A @ 250 VAC; 10 kA @ 125 VAC/VDC
- I²t
- 110 A²s nominal melting I²t
- Pre-arcing I²t
- 110
- Operating Temperature
- −55°C to +125°C
- Package / Dimensions
- 2AG (4.5×15mm)
- Mounting
- PCB Through-Hole
- Application
- Telecom DC distribution
- Standard
- UL/CSA/NMX 248-1 and 248-14
- Terminal Type
- Tin-plated copper axial leads
- Fuse Speed
- Time Delay
- Approvals
- CE · CSA · RoHS · UL Recognized
- Certifications
- UL; CSA; PSE; CE; RoHS; Lead-Free
- Series construction
- 230 Series axial-leaded 2AG Slo-Blo fuse
- Ordering configuration
- reel-and-tape packaging, 1,500 pieces, T3=73 mm
- Body/caps/leads
- Glass / nickel-plated brass / tin-plated copper
- Lead-free suffix
- P where shown in full order code
