Littelfuse 0230007VXP 7A 2AG Slo-Blo Axial Fuse
● Contact for Availability0230007VXP is a compact 7 A 2AG glass axial fuse in the Littelfuse 230 Series; this SKU uses bulk VX configuration.
Rated Current7 A
Rated Voltage125 V AC / 125 V DC
Breaking Capacity400 A @ 125 VAC/VDC
Package2AG (4.5×15mm)
QUICK RFQ
Request a quote for 0230007VXP
Submit directly from this product page. We will reply with availability, lead time and pricing.
Part Number0230007VXPBrandLittelfuseRequested Qty100
Part 0230007VXP brings 7 A time-delay performance to Littelfuse’s telecom-oriented 230 Series axial fuse format. Manufacturer data for this current level shows 464 A²s nominal melting I²t and 400 A @ 125 VAC/VDC. The ordering suffix denotes bulk packaging, 5-piece manufacturer pack code; this detail is useful when matching assembly and packaging requirements.
Technical Specifications
- Part Number
- 0230007VXP
- Manufacturer Part Number
- 0230007VXP
- Series
- 230 Series
- Fuse Type
- 2AG Glass Axial Lead Fuse
- Current Rating
- 7 A
- Voltage Rating
- 125 V AC / 125 V DC
- AC / DC
- AC/DC
- Breaking Capacity
- 400 A @ 125 VAC/VDC
- I²t
- 464 A²s nominal melting I²t
- Pre-arcing I²t
- 464
- Operating Temperature
- −55°C to +125°C
- Package / Dimensions
- 2AG (4.5×15mm)
- Mounting
- PCB Through-Hole
- Application
- Telecom DC distribution
- Standard
- UL/CSA/NMX 248-1 and 248-14
- Terminal Type
- Tin-plated copper axial leads
- Fuse Speed
- Time Delay
- Approvals
- CE · CSA · RoHS · UL Recognized
- Certifications
- UL; CSA; PSE; CE; RoHS; Lead-Free
- Series construction
- 230 Series axial-leaded 2AG Slo-Blo fuse
- Ordering configuration
- bulk packaging, 5-piece manufacturer pack code
- Body/caps/leads
- Glass / nickel-plated brass / tin-plated copper
- Lead-free suffix
- P where shown in full order code
