Littelfuse 0230007MXF32P 7A 2AG Formed-Lead Time-Delay Fuse

Name: Littelfuse 0230007MXF32P 7A 2AG Formed-Lead Time-Delay Fuse
Brand: Littelfuse
SKU: 0230007MXF32P

Part Number: 0230007MXF32P

● Contact for Availability

0230007MXF32P is a 7 A Littelfuse Slo-Blo 2AG axial fuse with 125 VAC / VDC rating and bulk MXF32 configuration.

Rated Current7 A

Rated Voltage125 V AC / 125 V DC

Breaking Capacity400 A @ 125 VAC/VDC

Package2AG (4.5×15mm)

Tags

0230007MXF32P 230 Series 2AG 7A Axial Fuse Littelfuse Slo-Blo

Littelfuse 0230007MXF32P uses a glass 2AG body and axial leads to deliver 7 A time-delay circuit protection. Manufacturer data for this current level shows 464 A²s nominal melting I²t and 400 A @ 125 VAC/VDC. The ordering suffix denotes bulk packaging, 1,000-piece F32 formed-lead configuration; this detail is useful when matching assembly and packaging requirements.

Technical Specifications

Part Number: 0230007MXF32P
Manufacturer Part Number: 0230007MXF32P
Series: 230 Series
Fuse Type: 2AG Glass Axial Lead Fuse
Current Rating: 7 A
Voltage Rating: 125 V AC / 125 V DC
AC / DC: AC/DC
Breaking Capacity: 400 A @ 125 VAC/VDC
I²t: 464 A²s nominal melting I²t
Pre-arcing I²t: 464
Operating Temperature: −55°C to +125°C
Package / Dimensions: 2AG (4.5×15mm)
Mounting: PCB Through-Hole
Application: Telecom DC distribution
Standard: UL/CSA/NMX 248-1 and 248-14
Terminal Type: Tin-plated copper axial leads
Fuse Speed: Time Delay
Approvals: CE · CSA · RoHS · UL Recognized
Certifications: UL; CSA; PSE; CE; RoHS; Lead-Free
Series construction: 230 Series axial-leaded 2AG Slo-Blo fuse
Ordering configuration: bulk packaging, 1,000-piece F32 formed-lead configuration
Body/caps/leads: Glass / nickel-plated brass / tin-plated copper
Lead-free suffix: P where shown in full order code
