Littelfuse 0230006DRT1P 6A 2AG Tape/Reel Time-Delay Fuse

Littelfuse

Littelfuse 0230006DRT1P 6A 2AG Tape/Reel Time-Delay Fuse

Part Number: 0230006DRT1P

● Contact for Availability

Littelfuse 230 Series 0230006DRT1P: 6 A Slo-Blo axial glass fuse, 125 VAC / VDC, with reel and tape DRT1 configuration.

Rated Current6 A

Rated Voltage125 V AC / 125 V DC

Breaking Capacity400 A @ 125 VAC/VDC

Package2AG (4.5×15mm)

Tags

0230006DRT1P 230 Series 2AG 6A Axial Fuse Littelfuse Slo-Blo

With a 6 A rating, Littelfuse 0230006DRT1P is a 2AG glass fuse built for Slo-Blo response and PCB through-hole use. The datasheet specifies 380 A²s nominal melting I²t together with 400 A @ 125 VAC/VDC. The ordering suffix denotes reel-and-tape packaging, 1,500 pieces, T1=53 mm; this detail is useful when matching assembly and packaging requirements.

Technical Specifications

Part Number: 0230006DRT1P
Manufacturer Part Number: 0230006DRT1P
Series: 230 Series
Fuse Type: 2AG Glass Axial Lead Fuse
Current Rating: 6 A
Voltage Rating: 125 V AC / 125 V DC
AC / DC: AC/DC
Breaking Capacity: 400 A @ 125 VAC/VDC
I²t: 380 A²s nominal melting I²t
Pre-arcing I²t: 380
Operating Temperature: −55°C to +125°C
Package / Dimensions: 2AG (4.5×15mm)
Mounting: PCB Through-Hole
Application: Telecom DC distribution
Standard: UL/CSA/NMX 248-1 and 248-14
Terminal Type: Tin-plated copper axial leads
Fuse Speed: Time Delay
Approvals: CE · CSA · RoHS · UL Recognized
Certifications: UL; CSA; PSE; CE; RoHS; Lead-Free
Series construction: 230 Series axial-leaded 2AG Slo-Blo fuse
Ordering configuration: reel-and-tape packaging, 1,500 pieces, T1=53 mm
Body/caps/leads: Glass / nickel-plated brass / tin-plated copper
Lead-free suffix: P where shown in full order code
