Littelfuse 0230004ERT2SP 4A Indicating 2AG Axial Fuse

Name: Littelfuse 0230004ERT2SP 4A Indicating 2AG Axial Fuse
Brand: Littelfuse
SKU: 0230004ERT2SP

Part Number: 0230004ERT2SP

● Contact for Availability

A 4 A axial-leaded 2AG time-delay fuse from Littelfuse 230 Series, 0230004ERT2SP is identified by its reel and tape ERT2S configuration order configuration.

Rated Current4 A

Rated Voltage125 V AC / 125 V DC

Breaking Capacity400 A @ 125 VAC/VDC

Package2AG (4.5×15mm)

Tags

0230004ERT2SP 230 Series 2AG 4A Axial Fuse Littelfuse Slo-Blo

Designed around the 230 Series 2AG platform, 0230004ERT2SP is a 4 A axial glass time-delay fuse. Its electrical table gives 148 A²s nominal melting I²t, with interrupting ratings of 400 A @ 125 VAC/VDC. For procurement, this SKU is differentiated by reel-and-tape packaging, 2,500 pieces, T2=63 mm with S option, while the core electrical rating follows the 230 Series data.

Technical Specifications

Part Number: 0230004ERT2SP
Manufacturer Part Number: 0230004ERT2SP
Series: 230 Series
Fuse Type: 2AG Glass Axial Lead Fuse
Current Rating: 4 A
Voltage Rating: 125 V AC / 125 V DC
AC / DC: AC/DC
Breaking Capacity: 400 A @ 125 VAC/VDC
I²t: 148 A²s nominal melting I²t
Pre-arcing I²t: 148
Operating Temperature: −55°C to +125°C
Package / Dimensions: 2AG (4.5×15mm)
Mounting: PCB Through-Hole
Application: Telecom DC distribution
Standard: UL/CSA/NMX 248-1 and 248-14
Terminal Type: Tin-plated copper axial leads
Fuse Speed: Time Delay
Approvals: CE · CSA · RoHS · UL Recognized
Certifications: UL; CSA; PSE; CE; RoHS; Lead-Free
Series construction: 230 Series axial-leaded 2AG Slo-Blo fuse
Ordering configuration: reel-and-tape packaging, 2,500 pieces, T2=63 mm with S option
Body/caps/leads: Glass / nickel-plated brass / tin-plated copper
Lead-free suffix: P where shown in full order code
Indicating option: S-code variant; glass body discolors after fuse operation
