Littelfuse 0230001MXF32P 1A 2AG Formed-Lead Time-Delay Fuse

Name: Littelfuse 0230001MXF32P 1A 2AG Formed-Lead Time-Delay Fuse
Brand: Littelfuse
SKU: 0230001MXF32P

Part Number: 0230001MXF32P

● Contact for Availability

0230001MXF32P is a 1 A Littelfuse Slo-Blo 2AG axial fuse with 250 VAC / 125 VDC rating and bulk MXF32 configuration.

Rated Current1 A

Rated Voltage250 V AC / 125 V DC

Breaking Capacity35 A @ 250 VAC; 10 kA @ 125 VAC/VDC; 80 A @ 310 VAC

Package2AG (4.5×15mm)

Tags

0230001MXF32P 1A 230 Series 2AG Axial Fuse Littelfuse Slo-Blo

With a 1 A rating, Littelfuse 0230001MXF32P is a 2AG glass fuse built for Slo-Blo response and PCB through-hole use. Manufacturer data for this current level shows 5.64 A²s nominal melting I²t and 35 A @ 250 VAC; 10 kA @ 125 VAC/VDC; 80 A @ 310 VAC. The 0.25–1.25 A range is also documented for short-duration surge withstand in telecom equipment. Its manufacturer order-code configuration is bulk packaging, 1,000-piece F32 formed-lead configuration; use the datasheet when validating packaging and lead-form requirements.

Technical Specifications

Part Number: 0230001MXF32P
Manufacturer Part Number: 0230001MXF32P
Series: 230 Series
Fuse Type: 2AG Glass Axial Lead Fuse
Current Rating: 1 A
Voltage Rating: 250 V AC / 125 V DC
AC / DC: AC/DC
Breaking Capacity: 35 A @ 250 VAC; 10 kA @ 125 VAC/VDC; 80 A @ 310 VAC
I²t: 5.64 A²s nominal melting I²t
Pre-arcing I²t: 5.64
Operating Temperature: −55°C to +125°C
Package / Dimensions: 2AG (4.5×15mm)
Mounting: PCB Through-Hole
Application: Telecom DC distribution
Standard: UL/CSA/NMX 248-1 and 248-14
Terminal Type: Tin-plated copper axial leads
Fuse Speed: Time Delay
Approvals: CE · CSA · RoHS · UL Recognized
Certifications: UL; CSA; PSE; CE; RoHS; Lead-Free
Series construction: 230 Series axial-leaded 2AG Slo-Blo fuse
Ordering configuration: bulk packaging, 1,000-piece F32 formed-lead configuration
Body/caps/leads: Glass / nickel-plated brass / tin-plated copper
Lead-free suffix: P where shown in full order code
Surge withstand: 0.25–1.25 A range supports specified telecom impulse requirements; see datasheet
