Littelfuse 0217015. 15A 5×20mm Fast-Acting Glass Cartridge Fuse

Name: Littelfuse 0217015. 15A 5×20mm Fast-Acting Glass Cartridge Fuse
Brand: Littelfuse
SKU: 0217015.

Part Number: 0217015.

● Contact for Availability

Order code 0217015.: 15A fast-acting Littelfuse 217 Series 5×20mm glass fuse, supplied as the base cartridge configuration.

Rated Current15A

Rated Voltage250 V AC

Breaking Capacity150 A @ 250 VAC

Package5×20mm

Tags

0217015.15A 217 Series 5×20mm catalog/base cartridge fast acting Littelfuse

Littelfuse 0217015. combines a 15 A rating, fast-acting response and 5×20mm glass fuse construction in the 217 Series family. The selected ordering variant is the base cartridge configuration. Electrical data includes 150 A @ 250 VAC interrupting capability and 607.135 A²s nominal melting I²t. For substitution or design-in, compare the exact package code, ambient derating and time-current behavior with the official datasheet.

Technical Specifications

Part Number: 0217015.
Manufacturer Part Number: 0217015.
Series: 217 Series
Fuse Type: 5×20mm Glass Cartridge Fuse
Current Rating: 15A
Voltage Rating: 250 V AC
AC / DC: AC
Breaking Capacity: 150 A @ 250 VAC
I²t: 607.135 A²s nominal melting I²t
Pre-arcing I²t: 607.135
Operating Temperature: -55°C to +125°C
Package / Dimensions: 5×20mm
Mounting: Cartridge / Clip
Application: Power Electronics
Standard: IEC 60127-2
Terminal Type: Nickel-plated brass end caps
Fuse Speed: Fast Acting (F)
Approvals: CE · RoHS
Certifications: CE; RoHS; additional agency approvals vary by rating/form
Package/configuration: Base catalog ordering code; glass body with nickel-plated brass caps. Nominal melting I²t: 607.135 A²s. Series operating temperature: -55°C to +125°C.
