Littelfuse

Littelfuse 0217.400MRET1P 0.4A 5×20mm Fast-Acting Glass Cartridge Fuse

Name: Littelfuse 0217.400MRET1P 0.4A 5×20mm Fast-Acting Glass Cartridge Fuse
Brand: Littelfuse
SKU: 0217.400MRET1P

Part Number: 0217.400MRET1P

● Contact for Availability

Order code 0217.400MRET1P: 0.4A fast-acting Littelfuse 217 Series 5×20mm glass fuse, supplied as the reel-and-tape configuration.

Rated Current0.4A

Rated Voltage250 V AC

Breaking Capacity35 A @ 250 VAC

Package5×20mm

Tags

0.4A 0217.400MRET1P 217 Series 5×20mm fast acting Littelfuse MRET1 reel-and-tape

Littelfuse part 0217.400MRET1P identifies a reel-and-tape configuration within the 217 Series 5×20mm glass fuse range. Key ratings are 0.4 A, 250 V AC, fast-acting operation, 35 A @ 250 VAC interrupting capability and 0.125 A²s nominal melting I²t. This page is keyed to the exact orderable variant rather than only the base series; check the latest datasheet for final circuit-protection selection.

Technical Specifications

Part Number: 0217.400MRET1P
Manufacturer Part Number: 0217.400MRET1P
Series: 217 Series
Fuse Type: 5×20mm Glass Cartridge Fuse
Current Rating: 0.4A
Voltage Rating: 250 V AC
AC / DC: AC
Breaking Capacity: 35 A @ 250 VAC
I²t: 0.125 A²s nominal melting I²t
Pre-arcing I²t: 0.125
Operating Temperature: -55°C to +125°C
Package / Dimensions: 5×20mm
Mounting: Cartridge / Clip
Application: Power Electronics
Standard: IEC 60127-2
Terminal Type: Nickel-plated brass end caps
Fuse Speed: Fast Acting (F)
Approvals: CE · RoHS · UL Recognized
Certifications: CE; RoHS; UL Recognized; additional agency approvals vary by rating/form
Package/configuration: Reel and Tape, 1000 pcs; glass body with nickel-plated brass caps. Nominal melting I²t: 0.125 A²s. Series operating temperature: -55°C to +125°C.
