Littelfuse 0216.500 0.5A 5×20mm Fast-Acting Ceramic Fuse

Name: Littelfuse 0216.500 0.5A 5×20mm Fast-Acting Ceramic Fuse
Brand: Littelfuse
SKU: 0216.500

Part Number: 0216.500

● Contact for Availability

Specified as 0216.500, this Littelfuse part carries a 0.5A rating; base catalog cartridge, with published series ratings and ordering-specific configuration.

Rated Current0.5A

Rated Voltage250 V AC

Breaking Capacity1500 A @ 250 VAC

Package5×20mm

Tags

0.5A 0216.500 216 Series 5×20mm Ceramic Fuse Base catalog cartridge Littelfuse

The 0216.500 configuration extends Littelfuse 216 Series coverage to a 0.5A rating in a fast-acting 5×20mm ceramic fuse format. The selected part uses base catalog cartridge. The full ordering code specifies base catalog cartridge, so package and lead details should be matched exactly. It is rated 250 V AC and the datasheet lists 1500 A @ 250 VAC interrupting capability. Nominal melting I²t is 0.165 A²s. Verify ambient derating, coordination and the exact manufacturer ordering code against the current Littelfuse datasheet before design-in.

Technical Specifications

Part Number: 0216.500
Manufacturer Part Number: 0216.500
Series: 216 Series
Fuse Type: 5×20mm Ceramic Fuse
Current Rating: 0.5A
Voltage Rating: 250 V AC
AC / DC: AC
Breaking Capacity: 1500 A @ 250 VAC
I²t: 0.165 A²s nominal melting I²t
Pre-arcing I²t: 0.165
Operating Temperature: -55°C to +125°C
Package / Dimensions: 5×20mm
Mounting: Cartridge / Clip
Application: Supplementary protection for appliances, utilization equipment, components and internal circuits
Standard: IEC 60127-2 · UL/CSA/NMX 248-1 and 248-14
Terminal Type: Nickel-plated brass end caps
Fuse Speed: Fast Acting (F)
Approvals: CE · CSA · RoHS · UL Recognized
Certifications: CE; RoHS; UL/CSA recognition and other approvals vary by rating/form
Package/configuration: Base catalog cartridge. Ceramic body; nickel-plated brass caps. Nominal melting I²t: 0.165 A²s. Series operating temperature: -55°C to +125°C.
