Littelfuse 0215.200 0.2 A 250 V Time-Lag 5×20 mm Ceramic Fuse – Cartridge

Name: Littelfuse 0215.200 0.2 A 250 V Time-Lag 5×20 mm Ceramic Fuse – Cartridge
Brand: Littelfuse
SKU: 0215.200

Part Number: 0215.200

● Contact for Availability

0215.200 is a Littelfuse 0.2 A time-lag 5×20 mm ceramic cartridge for supplementary protection for appliances, utilization equipment, components and internal circuits, with 1.5 kA @ 250 V AC interrupting capability.

Rated Current0.2 A

Rated Voltage250 V AC

Breaking Capacity1.5 kA @ 250 V AC

Package5×20mm Ceramic

Tags

0.2A 0215.200 215 Series 250 V AC 5×20mm Ceramic IEC 5×20 mm Littelfuse Time-Lag

The 0215.200 order code identifies a Littelfuse 215 fuse with a 0.2 A current rating and time-lag response. Typical use includes supplementary protection for appliances, utilization equipment, components and internal circuits. The series is built to IEC 60127-2 and rated 1.5 kA @ 250 V AC for fault interruption. The ordering suffix distinguishes this SKU as catalog/base part; verify package suffix when ordering. Verify coordination, derating and suitability against the current Littelfuse datasheet before design-in.

Technical Specifications

Part Number: 0215.200
Manufacturer Part Number: 0215.200
Series: 215 Series
Fuse Type: 5×20 mm ceramic cartridge fuse
Current Rating: 0.2 A
Voltage Rating: 250 V AC
AC / DC: AC
Breaking Capacity: 1.5 kA @ 250 V AC
I²t: 0.34 A²s nominal melting I²t
Pre-arcing I²t: 0.34
Operating Temperature: -55 °C to +125 °C
Package / Dimensions: 5×20mm Ceramic
Mounting: Cartridge / Clip · Fuse Holder
Application: Supplementary protection for appliances, utilization equipment, components and internal circuits
Standard: GB 9364.1 / 9364.2 · IEC 60127-2 · UL/CSA/NMX 248-1 and 248-14
Terminal Type: Nickel-plated brass end caps
Fuse Speed: Time Delay
Utilization Class: IEC 5×20 mm
Approvals: Agency approvals vary by rating
Certifications: UL/CSA/NMX recognized; PSE; CCC; KC; CE; VDE and other approvals by amp/package
Sample Status: Contact for sample availability
Ceramic body, nickel-plated brass caps; surge-withstand time-lag construction. Package: catalog/base part; verify package suffix when ordering.
