Littelfuse 0213005.MXEP 5A 5×20mm Time-Lag Glass Fuse

Name: Littelfuse 0213005.MXEP 5A 5×20mm Time-Lag Glass Fuse
Brand: Littelfuse
SKU: 0213005.MXEP

Part Number: 0213005.MXEP

● Contact for Availability

0213005.MXEP is a 5A Littelfuse 213 Series device; axial lead, bulk, with published series ratings and ordering-specific configuration.

Rated Current5A

Rated Voltage250 V AC

Breaking Capacity35 A @ 250 VAC

Package5×20mm

Tags

0213005.MXEP 213 Series 5×20mm Glass Fuse 5A Axial lead, bulk Littelfuse

Use 0213005.MXEP when a 5A Littelfuse time-lag 5×20mm glass fuse is required and the exact ordering configuration must be retained. The selected part uses axial lead, bulk. The full ordering code specifies axial lead, bulk, so package and lead details should be matched exactly. It is rated 250 V AC and the datasheet lists 35 A @ 250 VAC interrupting capability. Nominal melting I²t is 314 A²s. Verify ambient derating, coordination and the exact manufacturer ordering code against the current Littelfuse datasheet before design-in.

Technical Specifications

Part Number: 0213005.MXEP
Manufacturer Part Number: 0213005.MXEP
Series: 213 Series
Fuse Type: 5×20mm Glass Fuse
Current Rating: 5A
Voltage Rating: 250 V AC
AC / DC: AC
Breaking Capacity: 35 A @ 250 VAC
I²t: 314 A²s nominal melting I²t
Pre-arcing I²t: 314
Operating Temperature: -55°C to +125°C
Package / Dimensions: 5×20mm
Mounting: PCB Axial Lead · PCB Through-Hole
Application: Supplementary protection for appliances, utilization equipment, components and internal circuits
Standard: IEC 60127-2 Sheet 3 · UL/CSA/NMX 248-1 and 248-14
Terminal Type: Tin-plated copper axial leads
Fuse Speed: Time Delay
Approvals: CCC · CE · CSA · RoHS · UL Recognized · VDE
Certifications: CE; RoHS; UL Recognized; CSA; VDE; CCC; approvals vary by rating/form
Package/configuration: Axial lead, bulk. Glass body; tin-plated copper leads. Nominal melting I²t: 314 A²s. Series operating temperature: -55°C to +125°C.
