Eaton Bussmann LPS-RK-9SP 9A 600V AC / 300V DC Class RK1 Fuse
● Contact for AvailabilityLPS-RK-9SP: 9A, 600V AC / 300V DC, Class RK1, Time-Delay|Dual Element; 300kA AC / 100kA DC.
Rated Current9A
Rated Voltage600V AC / 300V DC
Breaking Capacity300kA AC / 100kA DC
PackageClass RK1
QUICK RFQ
Request a quote for LPS-RK-9SP
Submit directly from this product page. We will reply with availability, lead time and pricing.
Part NumberLPS-RK-9SPBrandEaton BussmannRequested Qty100
Eaton Bussmann LPS-RK-9SP is a Class RK1 time-delay|dual element branch circuit fuse rated 9A at 600V AC / 300V DC. Interrupting rating: 300kA AC / 100kA DC. Source: Bussmann Full Line Catalog 1007 (2018), section 1, page 1-24 to 1-26.
Technical Specifications
- Part Number
- LPS-RK-9SP
- Manufacturer Part Number
- LPS-RK-9SP
- Series
- LPS-RK Series (Class RK1 Low-Peak Dual-Element Time-Delay)
- Fuse Type
- Branch Circuit Fuse
- Current Rating
- 9A
- Voltage Rating
- 600V AC / 300V DC
- AC / DC
- AC/DC
- Breaking Capacity
- 300kA AC / 100kA DC
- Package / Dimensions
- Class RK1
- Mounting
- Fuse Holder
- Application
- Distribution switchboards · Machinery Disconnects · Motor control centers · Power Panelboards
- Standard
- CSA C22.2 No. 248.12 · UL 248-12
- Terminal Type
- Ferrule / knife blade by amp rating
- Fuse Speed
- Dual Element · Time Delay
- Utilization Class
- Class RK1
- Approvals
- CE · CSA · UL Listed
- Certifications
- UL Listed|CSA Certified|CE
- Reference Lead Time
- LT: 12-16w
- Minimum Order
- 12-16 weeks
- Source
- Bussmann Full Line Catalog 1007 (2018), section 1, page 1-24 to 1-26.
