Eaton Bussmann H75ESS-30-PCB 30A 750V DC aR High-Speed Fuse

Name: Eaton Bussmann H75ESS-30-PCB 30A 750V DC aR High-Speed Fuse
Brand: Eaton Bussmann
SKU: H75ESS-30-PCB

Part Number: H75ESS-30-PCB

● Check availability

H75ESS-30-PCB combines a 30A rating, 750V DC capability and 50kA breaking capacity in a compact Bussmann fuse.

Rated Current30A

Rated Voltage750V DC

Breaking Capacity50kA

Tags

aR Fuse bussmann fuse dc fuse High-Speed Fuse

The Bussmann H75ESS-30-PCB DC fuse offers a 30A rating and 750V DC voltage class in a cylindrical pcb terminal package. With 50kA breaking capacity and low I²t, it is intended for fast fault protection in power-electronic circuits.

Technical Specifications

Part Number: H75ESS-30-PCB
Manufacturer Part Number: H75ESS-30-PCB
Series: H75ESS Series
Fuse Type: Compact High-Speed DC Fuse
Current Rating: 30A
Voltage Rating: 750V DC
AC / DC: DC
Breaking Capacity: 50kA
I²t: Pre-arcing 90 A²s; total 400 A²s
Pre-arcing I²t: 90
Total I²t: 400
Mounting: PCB Mount
Application: DC semiconductor protection · Power Electronics / Semiconductor Protection
Standard: UL 248-13
Terminal Type: PCB Terminal
Fuse Speed: High-Speed
Utilization Class: aR
Power loss: 10 W at In; 6 W at 0.8×In; 2 W at 0.5×In.
