Bussmann CCP2-2-60CF 600V AC / 125V DC 60A CCP2 Class CF Fused Disconnect Switch

Name: Bussmann CCP2-2-60CF 600V AC / 125V DC 60A CCP2 Class CF Fused Disconnect Switch
Brand: Eaton Bussmann
SKU: CCP2-2-60CF

Part Number: CCP2-2-60CF

● LT: 12-16w

CCP2 Class CF fusible disconnect switch, 60A, 600 Vac / 125 Vdc, 200 kA AC SCCR.

Rated Current60A

Rated Voltage600 Vac / 125 Vdc

Breaking Capacity200 kA AC / 100 kA DC

Package2-pole

Tags

60A bussmann CCP2 CCP2-2-60CF Class CF eaton bussmann fused disconnect switch RoHS UL 98

Bussmann CCP2-2-60CF Compact Circuit Protector (CCP2), UL 98 Class CF fused disconnect switch, 60A, 2-pole, 600 Vac / 125 Vdc, switch-only. Rated 200 kA AC SCCR and designed for UL Class CF CUBEFuse applications. DC rating depends on installed fuse ampere rating (see Eaton Data Sheet 10801).

Technical Specifications

Part Number: CCP2-2-60CF
Manufacturer Part Number: CCP2-2-60CF
Series: CCP2 Class CF (60A)
Fuse Type: Fused Disconnect Switch
Current Rating: 60A
Voltage Rating: 600 Vac / 125 Vdc
AC / DC: AC/DC
Breaking Capacity: 200 kA AC / 100 kA DC
I²t: 0 A²s
Operating Temperature: -20C to 75C (-4F to 167F)
Package / Dimensions: 2-pole
Mounting: DIN Rail Mount
Application: Branch Circuit Protection · Motor protection · Power Distribution Protection
Standard: UL 98
Terminal Type: Box Lug / Fork
Fuse Speed: N/A
Utilization Class: Class CF
Approvals: cULus · RoHS · UL Listed
Certifications: UL Listed|cULus|RoHS
Reference Lead Time: 12-16 weeks
Minimum Order: 10 pcs
Sample Status: Contact for Availability
Product type: CCP2 Class CF fused disconnect switch
Catalog number: CCP2-2-60CF
Poles: 2
Rated current: 60A
Voltage: 600 Vac / 125 Vdc
Operation: switch-only
AC SCCR: 200 kA
Fuse system: UL Class CF CUBEFuse
