Eaton Bussmann 170M4619 900A 550V AC aR High-Speed Fuse

Eaton Bussmann

Eaton Bussmann 170M4619 900A 550V AC aR High-Speed Fuse

Part Number: 170M4619

● Contact for Availability

Eaton Bussmann 170M4619 900A 550V AC aR high-speed fuse for semiconductor and power-electronics protection.

Rated Current900A

Rated Voltage550V AC

Breaking Capacity200kA

PackageSize 1

Tags

170M aR Fuse eaton bussmann High-Speed Fuse Semiconductor Fuse

Eaton Bussmann 170M4619 is a 900A, 550V AC, aR high-speed square-body fuse in the 170M series for semiconductor, converter, rectifier and drive protection. It is designed for very fast current limitation in power-electronics circuits. Refer to the linked Eaton documentation for installation details and coordination data.

Technical Specifications

Part Number: 170M4619
Manufacturer Part Number: 170M4619
Series: 170M
Current Rating: 900A
Voltage Rating: 550V AC
AC / DC: AC
Breaking Capacity: 200kA
I²t: Pre-arcing 155000 A²s; clearing 850000 A²s at 660V AC
Pre-arcing I²t: 155000
Total I²t: 850000
Package / Dimensions: Size 1
Mounting: Bolted Tag
Application: Power Electronics
Standard: IEC 60269-4
Terminal Type: US Style Bolted Tag
Fuse Speed: Very Fast Acting
Utilization Class: aR
Approvals: CE · IEC Rated
Certifications: CE · IEC Rated
Manufacturer: Eaton Bussmann
Rated current: 900A
Rated voltage: 550V AC
Working class: aR
Fuse size: Size 1

Downloads

DatasheetOpen / download →
