Bussmann 170M1832 450A 1000V DC 170M IGBT high-speed square-body fuse
● LT: 4-6wEaton Bussmann 170M1832, 450A, 1000V DC, Class aR; interrupting rating 50kA DC @ 1000V.
Rated Current450A
Rated Voltage1000V DC
Breaking Capacity50kA DC @ 1000V
PackageSquare Body Size 230
QUICK RFQ
Request a quote for 170M1832
Submit directly from this product page. We will reply with availability, lead time and pricing.
Part Number170M1832BrandEaton BussmannRequested Qty100
Eaton Bussmann 170M1832 is a 170M Class aR IGBT high-speed square-body fuse rated 450A at 1000V DC. Interrupting rating: 50kA DC @ 1000V. Typical application: IGBT protection|DC drives|Power converters|Energy storage. Standard(s): IEC 60269-4|UL 248-1.
Technical Specifications
- Part Number
- 170M1832
- Manufacturer Part Number
- 170M1832
- Series
- 170M Series (1000V)
- Fuse Type
- High-Speed Square Body Fuse
- Current Rating
- 450A
- Voltage Rating
- 1000V DC
- AC / DC
- DC
- Breaking Capacity
- 50kA DC @ 1000V
- I²t
- 260,000 A²s
- Pre-arcing I²t
- 52,000 A²s
- Total I²t
- 260000
- Operating Temperature
- -40°C to +125°C
- Package / Dimensions
- Square Body Size 230
- Mounting
- Bolt-Down (FU/90: USR; FN/90: Metric)
- Application
- DC drives · Energy Storage · IGBT protection · Power converters
- Standard
- IEC 60269-4 · UL 248-1
- Terminal Type
- Bolted tag (FU/90: USR standard; FN/90: Metric)
- Fuse Speed
- High-Speed (aR)
- Utilization Class
- aR
- Approvals
- CE · UL Recognized
- Certifications
- UL Recognized|IEC 60269-4|CE
- Reference Lead Time
- 4–6 weeks
- Minimum Order
- 10 pcs
- Sample Status
- Contact for Availability
- Clearing I²t @ 1000V
- 260,000 A²s
- Watt Loss @ In
- 85W
