This Littelfuse to Bussmann cross reference chart maps Littelfuse fuse part numbers to their Eaton Bussmann equivalents — and works in reverse: if you hold a Bussmann part and need the Littelfuse substitute, use the second table.
Littelfuse to Bussmann (67)
| Littelfuse Part | Bussmann Equivalent | Amp | Voltage | Details |
|---|---|---|---|---|
| 211(amp) | GDC-(amp) | 6.3A | 250V AC | View |
| 212(amp) | GDB-(amp) | 6.3A | 250V AC | View |
| 213(amp) | GDC-(amp) | 6.3A | 250V AC | View |
| 215(amp) | S505-(amp) | 12A | 250V AC | View |
| 216(amp) | GDA-(amp) | 16A | 250V AC | View |
| 217(amp) | GDB-(amp) | 6.3A | 250V AC | View |
| 218(amp) | GDC-(amp) | 6.3A | 250V AC | View |
| 221(amp) | S505-V-(amp) | View | ||
| 226(amp) | GDA-V-(amp) | View | ||
| 227(amp) | GDB-V-(amp) | View | ||
| 228(amp) | GDC-V-(amp) | View | ||
| 230(amp) | C515-(amp) | 1.25A | 250V AC / 32V DC | View |
| 235(amp) | GMA-(amp) | 15A | 125V AC / 32V DC | View |
| 236(amp) | GMA-V-(amp) | 20A | 250V AC | View |
| 238(amp) | GMD-V-(amp) | View | ||
| 239(amp) | GMD-(amp) | View | ||
| 257(amp) | ATC-(amp) | 7.5 A | 32 V DC | View |
| 299(amp) | MAX-(amp) | 100A | 32V DC | View |
| 2AG220 | C517-(amp) | 3A | 350V AC / 32V DC | View |
| 2AG230 | C515-(amp) | 1.25A | 250V AC / 32V DC | View |
| 301(amp) | AGA-(amp) | 1.5A | 125V AC / 32V DC | View |
| 303(amp) | AGW-(amp) | 1A | 32V AC/DC | View |
| 307(amp) | SFE-(amp) | View | ||
| 311(amp) | AGC-(amp) | 30A | 250V AC | View |
| 312(amp) | AGC-(amp) | 30A | 250V AC | View |
| 313(amp) | MDL-(amp) | 30A | 250V AC | View |
| 314(amp) | ABC-(amp) | 30A | 250V AC | View |
| 315(amp) | MDL-V-(amp) | View | ||
| 318(amp) | AGC-V-(amp) | View | ||
| 322(amp) | GBB-(amp) | 1.25A | 250V AC / 125V DC | View |
| 323(amp) | MDA-(amp) | 30A | 250V AC | View |
| 324(amp) | ABC-V-(amp) | View | ||
| 325(amp) | MDA-V-(amp) | View | ||
| 326(amp) | MDA-(amp) | 30A | 250V AC | View |
| 334(amp) | GLD-(amp) | 1.5A | 125V AC | View |
| 336(amp) | GBA-(amp) | 1A | 125V AC | View |
| 361(amp) | AGX-(amp) | 1A | 250V AC / 32V DC | View |
| 362(amp) | AGX-(amp) | 1A | 250V AC / 32V DC | View |
| 3AB(amp) | ABC-(amp) | View | ||
| 3ABP(amp) | AGC-V-(amp) | View | ||
| 3AG(amp) | AGC-(amp) | 30A | 250V AC | View |
| 3AG311(amp) | AGC-(amp) | 30A | 250V AC | View |
| 3AG312(amp) | AGC-(amp) | 30A | 250V AC | View |
| 3AG313(amp) | MDL-(amp) | 30A | 250V AC | View |
| 3AG315(amp) | MDL-V-(amp) | View | ||
| 3AG318(amp) | AGC-V-(amp) | View | ||
| 3SB(amp) | MDL-(amp) | 30A | 250V AC | View |
| 3SBP(amp) | MDL-V-(amp) | View | ||
| 413(amp) | MDM-(amp) | View | ||
| 414(amp) | ABS-(amp) | 30A | 250V AC | View |
| 417(amp) | ABS-(amp) | 30A | 250V AC | View |
| 418(amp) | TR/3216FF-(amp) | View | ||
| 429(amp) | 3216FF(amp) | 7 A | 32 V DC | View |
| 431(amp) | 0603FA(amp) | 750 mA | 32 V AC/DC | View |
| 5140(amp) | BAF-(amp) | 30A | 250V AC | View |
| 5170(amp) | AGU-(amp) | View | ||
| 523(amp) | FNM-(amp) | 30A | 250V AC | View |
| 5HF(amp) | GDA-(amp) | 16A | 250V AC | View |
| 5HFP(amp) | GDA-V-(amp) | View | ||
| 5HT(amp) | S505-(amp)A | View | ||
| 5MF(amp) | GMA-(amp) | 15A | 125V AC / 32V DC | View |
| 5MFP(amp) | GMA-V-(amp) | 20A | 250V AC | View |
| 5SF(amp) | GDB-(amp) | 6.3A | 250V AC | View |
| 5ST(amp) | GDC-(amp) | 6.3A | 250V AC | View |
| KLK(amp) | KTK-(amp) | 30A | 600V AC | View |
| KLKR(amp) | KTK-R-(amp) | 9A | 600V AC | View |
| KLMR(amp) | LP-CC-(amp) | 9A | 600V AC / 150V DC | View |
Bussmann to Littelfuse (1)
| Bussmann Part | Littelfuse Equivalent | Amp | Voltage | Details |
|---|---|---|---|---|
| 170M | PSR | View |
Ratings shown are for the equivalent part; confirm continuous current, voltage class and breaking capacity on the detail page before substituting. For matches involving other brands, use the fuse cross reference tool.
